Control Arm/HYUNDAI/KIA/CEE'D Hatchback (ED)/CEE'D SW (ED)/i30 (FD) | AVANTE/i30 (GD)/i30 Coupe/i30 Estate (FD)/i30 Estate (GD)/PRO CEE'D (ED)

CS-2620R

Designation Control Arm
Position FRONT LOWER RH
OE No. 54501-1D000 / 54501-1D100 / 54501-1D300 / 54501-2G501 / 54501-2G600 / 54501-2G601 / 54501-2H000 / 54501-2H100
Length 486 mm
Width 400 mm
Height 56 mm
Net Weight 4.16 kg
CTE No. DESIGNATION POSITION OE NO.
Model (Year)
ELANTRA IV Saloon (HD) | AVANTE
i30 (FD) | ELANTRA | AVANTE
i30 Estate (FD)
Model (Year)
CARENS I MPV (FC, FJ)
CARENS III MPV (UN) | RONDO
CEE'D Hatchback (ED)
CEE'D SW (ED)
PRO CEE'D (ED)
