CS-2108
| Designation | Control Arm |
| Position | REAR LOWER LH/ RH |
| OE No. | 201 350 27 53 / 201 350 29 53 / 201 350 32 53 / 201 359 19 53 / 210 350 06 53 / 210 350 09 53 / 210 350 14 53 / 210 350 18 53 / A201 350 19 53 / A201 350 27 53 / A201 350 32 53 / A210 350 06 53 / A210 350 14 53 / A210 350 18 53 |
| Length | 0 mm |
| Width | 0 mm |
| Height | 0 mm |
| Net Weight | 0.58 kg |
| CTE No. | DESIGNATION | POSITION | OE NO. | |
|---|---|---|---|---|
 |
CBH21005 | FRONT LOWER ARM INNER | 210 333 55 14 A210 333 55 14 |
|
 |
CBH21006 | FRONT LOWER ARM REAR | 210 333 60 14 210 333 68 14 A210 333 60 14 A210 333 68 14 |
|
 |
CBH21007 | FRONT UPPER ARM INNER | ||
 |
CBH21013 | REAR AXLE UPPER | 124 352 90 65 A124 352 90 65 |
|
 |
CBH21014 | REAR AXLE UPPER | 124 350 05 75 124 352 35 65 A124 350 01 29 A124 350 05 75 |
|
 |
CBH21015 | REAR AXLE LOWER | 124 352 43 65 201 352 87 65 201 352 88 65 A124 352 43 65 A201 352 87 65 A201 352 88 65 |
|
 |
CBJ21002 | FRONT LOWER LH/ RH | 05099237AA 05099237AB 202 333 00 27 210 330 00 35 210 330 04 27 210 333 04 27 211 330 03 35 220 330 06 35 310 333 04 27 5099237AA 5099237AB A202 333 00 27 A210 330 00 35 A210 330 04 27 A210 333 04 27 A211 330 03 35 A220 330 06 35 A310 333 04 27 K05099237A |
|
 |
CS-2103L | FRONT LOWER LH | 210 330 34 07 210 330 44 07 210 330 55 07 210 330 61 07 210 330 610 705 210 330 76 07 210 330 90 07 210 330 93 07 210 330 95 07 A210 330 34 07 A210 330 44 07 A210 330 55 07 A210 330 61 07 A210 330 610 705 A210 330 76 07 A210 330 90 07 A210 330 93 07 A210 |
|
 |
CS-2103R | FRONT LOWER RH | 210 330 35 07 210 330 45 07 210 330 56 07 210 330 62 07 210 330 620 705 210 330 77 07 210 330 91 07 210 330 94 07 210 330 96 07 A210 330 35 07 A210 330 45 07 A210 330 56 07 A210 330 62 07 A210 330 620 705 A210 330 77 07 A210 330 91 07 A210 330 94 07 A210 |
|
 |
CS-2104L | FRONT UPPER LH | 202 330 36 07 202 330 48 07 208 330 04 07 208 330 13 07 210 330 22 07 210 330 25 07 210 330 50 07 210 330 87 07 |
|
 |
CS-2104R | FRONT UPPER RH | 202 330 37 07 202 330 49 07 208 330 05 07 208 330 14 07 210 330 23 07 210 330 26 07 210 330 51 07 210 330 88 07 |
|
 |
CS-2105L | REAR UPPER LH | 124 350 22 06 124 350 26 06 124 350 70 06 124 350 76 06 129 350 04 06 210 350 16 06 210 350 24 06 A124 350 22 06 A124 350 26 06 A124 350 70 06 A124 350 76 06 A129 350 04 06 A210 350 16 06 |
|
 |
CS-2105R | REAR UPPER RH | 124 350 23 06 124 350 27 06 124 350 71 06 124 350 77 06 129 350 05 06 129 350 09 06 201 350 33 06 210 350 17 06 210 350 25 06 A124 350 23 06 A124 350 27 06 A124 350 71 06 A124 350 77 06 A129 350 05 06 A129 350 09 06 A201 350 33 06 A210 350 17 06 |
|
 |
CS-2106 | REAR AXLE LH/ RH | 124 350 42 06 201 350 39 06 201 350 43 06 201 350 44 06 201 350 47 06 201 350 56 06 210 350 33 06 A124 350 42 06 A201 350 39 06 A201 350 43 06 A201 350 44 06 A201 350 47 06 A201 350 56 06 A210 350 33 06 K05099785AA |
|
 |
CS-2107 | REAR LOWER LH/ RH | 124 350 01 29 201 350 00 29 210 350 00 29 210 350 38 06 |
|
 |
CS-2108 | REAR LOWER LH/ RH | 201 350 27 53 201 350 29 53 201 350 32 53 201 359 19 53 210 350 06 53 210 350 09 53 210 350 14 53 210 350 18 53 A201 350 19 53 A201 350 27 53 A201 350 32 53 A210 350 06 53 A210 350 14 53 A210 350 18 53 |
|
 |
CSL21005 | REAR (A= 197MM) | 124 320 02 64 124 320 02 89 124 320 04 89 124 326 01 16 A124 320 02 89 |
|
 |
CSL21012L | FRONT LH (A= 115MM) | 210 320 21 89 210 320 36 89 A 210 320 21 89 A 210 320 36 89 |
|
 |
CSL21012R | FRONT RH (A= 115MM) | 210 320 22 89 210 320 37 89 A 210 320 22 89 A 210 320 37 89 |
| Model (Year) |
|---|
|
124 Coupe (C124) 124 Saloon (W124) 124 T-Model (S124) 190 (W201) C-CLASS (W202) C-CLASS T-Model (S202) CLK (C208) CLK Convertible (A208) E-CLASS (W124) E-CLASS (W210) E-CLASS Coupe (C124) E-CLASS T-Model (S124) E-CLASS T-Model (S210) S-CLASS (W140) SL (R129) SLK (R170) |
