CS-1003L
| Designation | Control Arm |
| Position | FRONT LOWER LH |
| OE No. | 54501-00Q0D / 54501-00Q0G / 54501-00Q0K / 54501-00Q0L / 54501-00QAG / 54501-00QAH / 77 00 310 809 / 77 00 313 944 / 77 00 425 227 / 82 00 197 179 / 82 00 737 123 / 82 00 942 407 / 82009-42417 |
| Length | 339 mm |
| Width | 239 mm |
| Height | 88.7 mm |
| Net Weight | 2.21 kg |
| CTE No. | DESIGNATION | POSITION | OE NO. | |
|---|---|---|---|---|
 |
CS-1003L | FRONT LOWER LH | 54501-00Q0D 54501-00Q0G 54501-00Q0K 54501-00Q0L 54501-00QAG 54501-00QAH 77 00 310 809 77 00 313 944 77 00 425 227 82 00 197 179 82 00 737 123 82 00 942 407 82009-42417 |
|
 |
CS-1003R | FRONT LOWER RH | 54500-00Q0D 54500-00Q0J 54500-00Q0M 54500-00Q1A 54500-00QAG 54500-00QAH 54616-00Q0D 77 00 310 810 77 00 313 945 77 00 425 228 82 00 197 187 82 00 737 129 82 00 942 408 82009-42413 |
| Model (Year) |
|---|
|
KUBISTAR Van (X76) |
| Model (Year) |
|---|
|
CLIO II (BB_, CB_) | LUTECIA CLIO II Hatchback Van (SB0/1/2_) KANGOO (KC0/1_) KANGOO Express (FC0/1_) THALIA I (LB_) | CLIO SYMBOL THALIA II (LU_) | SYMBOL |
