Repair Kit

COS21005

數量
已無庫存。若需選購，請與客服聯繫
Designation Repair Kit
Position
OE No.
Length 480 mm
Width 445 mm
Height 190 mm
Net Weight 17.49 kg
(W
O ABC)
CTE No. DESIGNATION POSITION OE NO.
CBH21023 FRONT LOWER ARM INNER
220 333 31 14
CBH21026 FRONT LOWER ARM INNER
220 333 18 14
A 220 333 18 14
CBH21051 FRONT UPPER ARM INNER
230 333 03 14
A230 333 03 14
CBJ21004 FRONT LOWER LH/ RH
211 323 00 68
211 323 03 68
220 323 03 68
A 211 323 00 68
A 211 323 03 68
A 220 323 03 68
CBJ21007 FRONT LOWER LH/ RH
211 330 02 35
211 330 04 35
220 330 04 27
220 333 01 27
220 333 02 27
220 333 03 27
220 333 04 27
220 333 04 37
220 333 07 27
A211 330 02 35
A211 330 04 35
A220 330 01 27
A220 330 03 27
A220 330 04 27
A220 333 01 27
A220 333 02 27
A220 333 03 27
A220 333
COS21005
CRE21001 D= M14X1.5 , C= M16X1.5
211 330 29 03
211 330 29 03 SK
220 338 07 15
230 338 00 15
230 338 00 15 SK
A211 330 29 03
A220 338 07 15
A230 338 00 15
CS-2118L FRONT LOWER LH (W/O ABC)
220 330 43 07
220 330 81 07
220 330 89 07
A 220 330 43 07
A 220 330 81 07
A 220 330 89 07
CS-2118R FRONT LOWER RH (W/O ABC)
220 330 44 07
220 330 82 07
220 330 90 07
A 220 330 44 07
A 220 330 82 07
A 220 330 90 07
CS-2123L FRONT LOWER LH
220 330 18 11
220 330 33 11
220 330 43 11
220 330 57 11
A 220 330 18 11
A 220 330 33 11
A 220 330 43 11
A 220 330 57 11
CS-2123R FRONT LOWER RH
220 330 17 11
220 330 34 11
220 330 44 11
220 330 58 11
A 220 330 17 11
A 220 330 34 11
A 220 330 44 11
A 220 330 58 11
CS-2129L FRONT UPPER LH
220 330 14 07
220 330 83 07
220 330 93 07
A220 330 14 07
A220 330 83 07
A220 330 93 07
CS-2129R FRONT UPPER RH
220 330 15 07
220 330 84 07
220 330 94 07
A220 330 15 07
A220 330 84 07
A220 330 94 07
CSL21038L FRONT AXLE LH
220 320 16 89
A220 320 16 89
CSL21038R FRONT AXLE RH
220 320 15 89
A220 320 15 89
CTE21009 FRONT AXLE LH/ RH
220 338 05 15
220 338 10 15
230 330 02 03
230 330 04 03
230 338 01 15
A220 338 05 15
A220 338 10 15
A230 330 02 03
A230 330 04 03
A230 338 01 15
Model (Year)
S-CLASS (W220)
