COS09019 優惠套餐是否有保固？

Name: COS09019
Brand: CTE
SKU: COS09019
Price: 8416 TWD
Availability: OutOfStock

Question

COS09019 優惠套餐 是否有保固？

Accepted Answer

CTE 對 優惠套餐 提供有限保固，詳細條款請參閱保固聲明頁面。

PARAMETER	METRIC / VALUE
Designation	Repair Kit
Position	Front Axle
OE 替代料號 (Original Equipment Numbers)
Length	465 mm
Width	345 mm
Height	180 mm
Net Weight	13.4 kg

CTE No.	DESIGNATION	POSITION	OE No.
CBH09024	RUBBER BUSHING	INNER; UPPER FRONT AXLE	31 12 6 771 199 31 12 6 772 995 31 12 6 772 996 31 12 6 772 997 31 12 6 772 998 31 12 6 776 417 31 12 6 776 417 SK1 31 12 6 776 418 31 12 6 776 418 SK1 31 12 6 788 981 31 12 6 788 982 31 12 6 790 973 31 12 6 790 974 31 12 6 790 975 31 12 6 790 976 31 12 6 863 787 6 771 199 6 776 417 6 776 418 6 863 787
CBH09027	RUBBER BUSHING	FRONT AXLE; LOWER; FRONT; INNER	31 10 6 778 015 31 12 6 851 693 31 12 6 863 171 6 778 015 6 851 693 6 863 171
CBH09091	RUBBER BUSHING		31 12 6 777 652 31 12 6 777 739 31 12 6 777 740 31 12 6 777 743 31 12 6 777 744 31 12 6 850 605 31 12 6 850 606 31 12 6 850 607 31 12 6 864 000 31 12 6 864 821 31 12 6 864 822
COS09018	KITS	FRONT AXLE
COS09019	KITS	FRONT AXLE
CRE09014	RACK END	FRONT AXLE LEFT; FRONT AXLE RIGHT	32 10 6 858 735 32 10 6 858 737
CS-934L	CONTROL ARM	FRONT AXLE LEFT; UPPER	31 12 2 413 489 31 12 6 776 417 31 12 6 776 995 31 12 6 776 997 31 12 6 863 333 31 12 6 863 335 31 12 6 863 785 6 776 417 6 863 785
CS-934R	CONTROL ARM	FRONT AXLE RIGHT; UPPER	31 12 2 413 488 31 12 6 776 418 31 12 6 776 996 31 12 6 776 998 31 12 6 863 334 31 12 6 863 786 32 12 6 863 336 6 776 418 6 863 786
CS-936L	CONTROL ARM	FRONT AXLE; LEFT; LOWER; FRONT	31 12 6 773 949 31 12 6 851 691 31 12 6 863 169 6 773 949 6 851 691 6 863 169
CS-936R	CONTROL ARM	FRONT AXLE; RIGHT; LOWER; FRONT	31 12 6 773 950 31 12 6 851 692 31 12 6 863 170 6 773 950 6 851 692 6 863 170
CS09118L	CONTROL ARM	REAR AXLE LEFT; UPPER; FRONT	33 32 4 046 917 33 32 6 770 963 33 32 6 779 387 33 32 6 795 047 4 046 917 6 770 963 6 779 387 6 795 047
CS09118R	CONTROL ARM	REAR AXLE RIGHT; UPPER; FRONT	33 32 4 046 918 33 32 6 770 964 33 32 6 779 388 33 32 6 795 048 4 046 918 6 770 964 6 779 388 6 795 048
CS09125L	CONTROL ARM	REAR AXLE LEFT; UPPER; REAR	33 32 6 770 969 33 32 6 796 001 6 770 969 6 796 001
CS09125R	CONTROL ARM	REAR AXLE RIGHT; UPPER; REAR	33 32 6 770 970 33 32 6 796 002 6 770 970 6 796 002
CS09144L	CONTROL ARM	FRONT AXLE; LOWER; REAR; LEFT	31 12 6 864 821 6 864 821
CS09144R	CONTROL ARM	FRONT AXLE; LOWER; REAR; RIGHT	31 12 6 864 822 6 864 822
CSL09021L	STABILIZER LINK	FRONT AXLE LEFT (A= 248MM)	31 35 6 773 023 31 35 6 857 623 31 35 6 859 651 6 773 023 6 857 623 6 859 651
CSL09021R	STABILIZER LINK	FRONT AXLE RIGHT (A= 248MM)	31 35 6 773 024 31 35 6 857 624 31 35 6 859 652 6 773 024 6 857 624 6 859 652
CSL09022	STABILIZER LINK	REAR AXLE LEFT; REAR AXLE RIGHT (A= 160MM)	33 55 6 771 937 33 55 6 857 626 6 771 937 6 857 626
CTE09029L	TIE ROD END	FRONT AXLE LEFT	32 10 6 858 736 32 10 6 863 858
CTE09029R	TIE ROD END	FRONT AXLE RIGHT	32 10 6 858 738 32 10 6 863 860
