Rubber Bushing

Rubber Bushing / CBH31025L

Technical Specification Matrix

CBH31025L 是 Rubber Bushing 專用的橡膠襯套 (Front; Lower Front Axle)。本產品為 OEM 規格替代零件，適配原廠料號 LR114249,LR146038,LR166007。

PARAMETER	METRIC / VALUE
Designation	Rubber Bushing
Position	Front; Lower Front Axle
OE 替代料號 (Original Equipment Numbers)	LR114249 LR146038 LR166007
Length	216 mm
Width	183 mm
Height	121 mm
Net Weight	4.1 kg

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

CTE No.	POSITION	OE No.
CBH31025L	FRONT; LOWER FRONT AXLE	LR114249 LR146038 LR166007
CBH31025R	FRONT; LOWER FRONT AXLE	LR114248 LR146037 LR166006
CBH31026	FRONT; LOWER FRONT AXLE	K8D2 3063 AA LR114248 LR114249 LR146037 LR146038
CS-3131L	FRONT AXLE LEFT	LR114249 LR146038 LR166007
CS-3131R	FRONT AXLE RIGHT	LR114248 LR146037 LR166006
CS-3140L	REAR AXLE LEFT; UPPER	J9C1717 J9C6196 LR060768 LR073526 LR078520 LR137510
CS-3140R	REAR AXLE RIGHT; UPPER	J9C1348 J9C6195 LR060763 LR073525 LR078519 LR137509
CS-3141L	REAR AXLE LEFT; LOWER; IN FRONT OF AXLE	LR090538 LR124618 LR128497 T4A1030 T4A13726 T4A37038
CS-3141R	REAR AXLE RIGHT; LOWER; IN FRONT OF AXLE	LR090537 LR124617 LR128496 T4A13725 T4A37037 T4A4225
CSL31020	FRONT AXLE LEFT; FRONT AXLE RIGHT	K8D23B438AA K8D23B438AB LR114253 LR186856
CTE32004	FRONT AXLE LEFT; FRONT AXLE RIGHT	J9C22780 K8D2-3C437-AA K8D2-3C437-AB LR135927
