CBH15012
| Designation | Rubber Bushing |
| Position | FRONT LOWER ARM REAR |
| OE No. | 03 52 365 / 090498740 / 35 23 65 / 90498740 |
| Length | 60 mm |
| Width | 60 mm |
| Height | 60 mm |
| Net Weight | 0.29 kg |
VAUXHALL ZAFIRA A (T98) VIN Code to 42125089, 4H
| CTE No. | DESIGNATION | POSITION | OE NO. | |
|---|---|---|---|---|
 |
CBH15005 | FRONT LOWER ARM INNER | 03 52 357 03 52 364 090468636 090498738 3 52 313 3 52 323 3 52 357 352 300 352 364 4566899 4645974 90157161 90468636 90498738 9191165 |
|
 |
CBH15012 | FRONT LOWER ARM REAR | 03 52 365 090498740 35 23 65 90498740 |
|
 |
CBJ15002A | FRONT LOWER LH/ RH | 03 52 800 03 52 829 090487561 090512982 3 52 800 3 52 829 90487561 90512982 90542995 |
|
 |
CRE15002 | D= M14X1.5 , C= M18X1.5 | 09118128 1603213 1603216 1603256 1603287 1603302 1603303 1603643 26059293 9118128 93179557 93189450 93191526 |
|
 |
CS-1507L | FRONT LOWER LH | 53 52 005 5352016 90496039 90498735 |
|
 |
CS-1507R | FRONT LOWER RH | 53 52 004 5352017 90496040 90498736 |
|
 |
CSL15006 | FRONT (A= 301.2MM) | 0 350 611 0 350 614 013169439 090498745 13169439 3 50 611 3 50 614 90498745 |
|
 |
CSL27006 | FRONT (A= 243.5MM) | 03 50 610 03 50 616 04 686 606 090496116 3 50 610 4 686 606 4686606 52 36 823 90496116 |
| Model (Year) |
|---|
|
ASTRA G CLASSIC (T98) ASTRA G CLASSIC Caravan (F35) ASTRA G CLASSIC Saloon (T98) ASTRA G Convertible (T98) ASTRA G Coupe (T98) ASTRA G Estate (T98) ASTRA G Estate Van (F70) ASTRA G Hatchback (T98) ASTRA G Saloon (T98) ZAFIRA A MPV (T98) |
| Model (Year) |
|---|
|
ASTRA Mk IV (G) Convertible (T98) ASTRA Mk IV (G) Coupe (T98) ASTRA Mk IV (G) Estate (T98) ASTRA Mk IV (G) Hatchback (T98) ASTRA Mk IV (G) Saloon (T98) ASTRAVAN Mk IV (G) Estate Van (T98) ZAFIRA A (T98) |
